Whitfield Pressure Switch Kit: 13640014

Product rating:
Product price:
$89.99
Product SKU ! 13640014
Product MPN ! 13640014
Product availability: In Stock
Bullet point features

Description

Pressure Switch Kit # 13640014 This part is compatible for: Quest Plus FS (WP4) Quest Insert (WP4) Advantage II Pellet Stove Freestanding & Insert WP2 - Model Years: 1989 - 1990 (Serial # 7401 - 18144).
The pressure switch in this kit is not the same as the factory original pressure switch (but it is equivalent).

Vacuum Switch Visual Note: The manufacturer of all OEM and AMP switches has made a design change. The switch received may appear different, but will work the same.



Replacement For Part Number:

  • 13640014

View Compatible Models

Compatible Models

    Whitfield

  • Advantage II INS (10348 - 18144)
  • Advantage II (10348 - 18144)
  • Advantage II-T
  • Quest FS WP4
  • Quest INS WP4
  • Quest Plus FS WP4

Technical Specs

Instructions

Install Instructions For Whitfield Pressure Switch Kit: 13640014

1. Remove pellet from hopper to expose rivets.

Suggestion: Place a towel over auger to prevent any metal debris falling into auger.

2. Open the left side stove panel.

3. Remove rear stove panel.

4. Disconnect the hose and wires from the original pressure switch.

5. Remove the original pressure switch by drilling out the two rivets from inside the hopper as follows:

  • Center punch the 2 rivet heads inside the hopper to leave dimples for centering drill bit.
  • Using a 11/64" drill bit, drill into each rivet head until the head comes free from the shank.
  • Tap out the rivet shanks using a 1/8" center punch. Remove old pressure switch and discard. With the rivets removed continue drilling the holes all the way through.

6. Install new pressure switch as follows.

Note: Switch must be mounted vertically.

  • Secure the pressure switch mounting bracket to the underside of the hopper by pressing in the new rivets with back-up rivet washers (using a rivet gun).

Note: The rivet head is inside of hopper and the washers are on the outside of the pressure switch bracket.

  • Connect the hose to the pressure switch using the plastic tie.
  • Connect wires to the terminals on pressure switch.
  • Reinstall rear panel and close side panel.
  • Inspect hopper - Ensure that no metal debris fell into the auger.

Troubleshooting

Do not remove the rivets using a chisel (to chip off the head of the rivet). This could oblong the rivet hole or tear the hopper skin.


Warranty

Unfortunately, sometimes products do not work like they are supposed to. We offer a 90 day warranty on manufacturer defects. Some manufacturers make this a very simple and easy process unfortunately others do not. Items must be used in accordance with the manufacturers guidelines to qualify for warranty replacement. Please be advised that warranty claims for these parts may take up to 4 weeks for processing, and customers must cover shipping.
